Is the Secop SC12CNX an OEM part, and what refrigerant does it use?

Yes, the SC12CNX is a genuine Secop compressor. It is specifically designed for use with R290 natural refrigerant.

What applications is the SC12CNX compressor suitable for?

The SC12CNX is suitable for low and medium temperature refrigeration systems, commonly found in commercial freezers and display cabinets.

What should I check before ordering the SC12CNX to ensure fitment?

Before ordering, verify the existing compressor's model number, confirm R290 refrigerant compatibility, and check the physical dimensions against your unit's space and mounting.

Secop SC12CNX R290 Compressor 1/2HP

$322.43 - $322.43

$322.43

$322.43 - $322.43

$322.43

🔧 Need the Right HVAC Tool for the Job? Whether you're quoting a bulk order or chasing hard-to-find tools, we’re here to help.

Get a fast, personalised quote—no pressure, no spam!
Fill out the form below and we’ll get back to you ASAP.

📩 Request a Quote

The SC12CNX is a Secop R290 refrigerant compressor. This 1/2 HP low and medium temperature unit is designed for environmentally focused refrigeration systems, including freezer and cabinet applications.

Part Identification

Part Number: SC12CNX
Manufacturer: Secop
Refrigerant: R290
Capacity: 1/2 HP

No supersession data is listed for this part number.

Where This Part Is Used

Environmentally focused refrigeration systems
Freezer applications
Cabinet applications
Low temperature applications
Medium temperature applications

Model coverage can change across production runs — confirm against your unit's data plate before ordering.

Specifications

Specification	Value
Refrigerant	R290
Capacity	1/2 HP
Displacement	12.87 cc
Cooling Capacity (-25°C)	474W
Height	209 mm
Weight	13.1 kg

Check Before You Order

Verify the existing compressor's model number against SC12CNX.
Confirm the system operates with R290 refrigerant.
Measure the physical dimensions and mounting points to ensure compatibility with your cabinet or freezer.
Check electrical supply requirements match the compressor specification.

Fitting Notes

Installation must be performed by an ARCtick licensed technician due to R290 refrigerant handling requirements.
Ensure proper evacuation and charging procedures are followed.
Verify correct oil type and charge volume for the system.
Securely mount the compressor to minimise vibration and noise.

Ordering & Availability

This is a genuine Secop R290 compressor. It is sold individually. Stock levels and current lead times are displayed at checkout. Order from HVAC Trade Supply.

Commonly Ordered With

Commonly ordered with suitable compressor oil, filter driers, and refrigerant access valves.
