Does this part number supersede, or is it superseded by, another number?

No supersession data is listed for the Secop SC15MNX compressor. Always verify the part number directly against your unit's requirements.

Which units or series does it fit, and how do I confirm against mine?

The Secop SC15MNX is designed for Secop S-series, stationary cooling, and medical cooling systems operating with R290 in Medium Back Pressure (MBP) applications. Confirm compatibility by matching your unit's data plate for voltage (115-127V/60Hz), refrigerant type, and application conditions.

Does fitting this part require a licensed tradesperson (ARCtick or electrical)?

Yes, installing this Secop SC15MNX compressor requires a current ARCtick licence due to its R290 (Propane) refrigerant, which is flammable. All associated electrical work must also be carried out by a licensed electrician.

Secop R290 MBP Compressor 115-127V/60Hz SC15MNX

$295.57 - $295.57

$295.57

$295.57 - $295.57

$295.57

🔧 Need the Right HVAC Tool for the Job? Whether you're quoting a bulk order or chasing hard-to-find tools, we’re here to help.

Get a fast, personalised quote—no pressure, no spam!
Fill out the form below and we’ll get back to you ASAP.

📩 Request a Quote

The Secop SC15MNX is a hermetic reciprocating compressor for R290 (Propane) refrigerant systems, designed for Medium Back Pressure (MBP) applications. This model operates on 115-127V/60Hz power supply and features a 15.28 cm³ displacement.

Part Identification

SKU: SC15MNX
Manufacturer Part Number (MPN): 104H7570 (primary variant)
Brand: Secop
Product Type: Compressor
No supersession data is listed for this part number.

Where This Part Is Used

Secop S-series compressors.
Stationary cooling solutions requiring R290 refrigerant.
Medical cooling applications.
Units operating in Medium Back Pressure (MBP) conditions.

Model coverage can change across production runs — confirm against your unit's data plate before ordering.

Specifications

Specification	Value
Power Supply	115-127V/60Hz
Refrigerant Compatibility	R290
Application Type	Medium Back Pressure (MBP)
Displacement	15.28 cm³
Oil Type	POE
Oil Charge	500 cm³
MBP Cooling Capacity (ASHRAE)	1396 W (at 3500 rpm for 104H7570)
Motor Type	CSIR
Height	219 mm
Weight	14.2 kg (for 104H7570)
Discharge Connector Ø	6.5 mm (Copper)
Process Connector Ø	6.5 mm (Copper)
Suction Connector Ø	9.63 mm (Copper)

Check Before You Order

Verify the system's data plate confirms 115-127V/60Hz power supply.
Confirm the system uses R290 (Propane) refrigerant and operates as a Medium Back Pressure (MBP) application.
Measure existing connector diameters to match the 6.5 mm discharge/process and 9.63 mm suction connections.
Check the existing compressor's displacement to ensure it matches 15.28 cm³.

Fitting Notes

Always isolate power and follow lockout/tagout procedures before commencing electrical work.
This compressor uses R290 (Propane), a flammable refrigerant. All work must be carried out by an ARCtick licensed technician following Australian Standards AS/NZS 60335.2.89 and AS/NZS 1677.2.
Evacuate the system thoroughly before charging. Use appropriate leak detection for R290.
Confirm the compressor mounting and electrical connections match the original unit.

Ordering & Availability

The Secop SC15MNX compressor is a genuine OEM part. Sold individually unless a pack quantity is shown above. Current stock levels and estimated lead times are displayed at checkout. Order from HVAC Trade Supply.

Commonly Ordered With

Consider ordering a new filter drier and appropriate POE refrigeration oil when replacing a compressor.
