Secop Low Temp Compressor R404A 220-240V | GS34CLX

$694.79 - $694.79

$694.79

$694.79 - $694.79

$694.79

🔧 Need the Right HVAC Tool for the Job? Whether you're quoting a bulk order or chasing hard-to-find tools, we’re here to help.

Get a fast, personalised quote—no pressure, no spam!
Fill out the form below and we’ll get back to you ASAP.

📩 Request a Quote

The Secop GS34CLX is a low temperature (LBP) hermetic compressor designed for R404A and R452A refrigerants. It operates on a 220-240V/50Hz power supply and features a 33.8 cm³ displacement.

Part Identification

Part Number: GS34CLX
Manufacturer Code: 107B0501, 107B0525
Brand: Secop
Part Category: Hermetic Compressor
No supersession data is listed for this part number.

Where This Part Is Used

Low Back Pressure (LBP) refrigeration systems.
Stationary refrigeration applications.
Medical cooling solutions.

Model coverage can change across production runs — confirm against your unit's data plate before ordering.

Specifications

Power Supply	220-240V/50Hz
Compatible Refrigerants	R404A, R452A
Application Type	LBP (Low Back Pressure)
Motor Type	CSCR
Height	279 mm
Weight	20 kg
Discharge Connector Ø	8.2 mm
Discharge Material	Copper
Process Connector Ø	6.5 mm
Process Material	Copper
Suction Connector Ø	12.9 mm
Suction Material	Copper
Displacement	33.8 cm³
Oil Charge	900 cm³
Oil Type	POE
Motor Speed	2900 rpm
LBP Cooling Capacity (ASHRAE)	1883 W
LBP COP (ASHRAE)	1.49 W/W

Check Before You Order

Verify the existing compressor's model number against GS34CLX on its data plate.
Confirm the system’s refrigerant type is R404A or R452A.
Ensure your electrical supply matches 220-240V/50Hz.
Measure all connection diameters: 12.9mm for suction, 8.2mm for discharge, and 6.5mm for process lines.
Confirm the system operates as a Low Back Pressure (LBP) application.

Fitting Notes

Ensure all electrical power to the unit is isolated and locked out before commencing work.
Recover all refrigerant from the system using approved equipment and an ARCtick licensed technician.
Replace the system’s filter drier and charge with fresh POE oil (900 cm³) during compressor replacement.
Evacuate the refrigeration system thoroughly to industry standards before introducing new refrigerant charge.
Installation and commissioning of this compressor require a licensed refrigeration mechanic with a current ARCtick licence.

Ordering & Availability

This is a genuine Secop compressor. Sold individually unless a pack quantity is shown above. Current stock levels and estimated lead times are provided at checkout. Order from HVAC Trade Supply.

Commonly Ordered With

Commonly ordered with a new liquid line filter drier, POE refrigeration oil, and appropriate R404A or R452A refrigerant.
