Does fitting this part require a licensed tradesperson?

Yes, installing the Secop NLE12.6CNL compressor requires an ARCtick-licensed technician due to refrigerant handling requirements.

Which units or series does it fit, and how do I confirm against mine?

The NLE12.6CNL is designed for LBP (Low Back Pressure) refrigeration systems and stationary medical cooling. Confirm fitment by cross-referencing the full model number and specifications on your unit's data plate before ordering.

What do I measure or check to be certain before I order?

Before ordering the NLE12.6CNL, verify the model number, confirm R290 refrigerant use, check the 220-240V/50Hz power supply, and measure the suction (8.2mm), discharge (6.2mm), and process (6.2mm) connector diameters.

Secop Compressor NLE12.6CNL R290 LBP 220-240V

$290.40 - $290.40

$290.40

$290.40 - $290.40

$290.40

🔧 Need the Right HVAC Tool for the Job? Whether you're quoting a bulk order or chasing hard-to-find tools, we’re here to help.

Get a fast, personalised quote—no pressure, no spam!
Fill out the form below and we’ll get back to you ASAP.

📩 Request a Quote

This is a Secop NLE12.6CNL fixed-speed compressor designed for Low Back Pressure (LBP) applications. It operates on 220-240V/50Hz power and uses R290 refrigerant.

Part Identification

Part Number: NLE12.6CNL
Brand: Secop
Category: Compressor
Manufacturer Codes: 105H6378, 105H6376
No supersession data is listed for this part number.

Where This Part Is Used

Low Back Pressure (LBP) refrigeration systems.
Stationary medical cooling solutions.

Model coverage can change across production runs — confirm against your unit's data plate before ordering.

Specifications

Specification	Value
Power Supply	220-240V/50Hz
Refrigerant	R290
Application	LBP (Low Back Pressure)
Motor Type	CSIR
Displacement	12.55 cm³
Oil Charge	300 cm³
Oil Type	POE
Height	203 mm
Weight	11.8 kg
Discharge Connector Diameter	6.2 mm (Copper)
Process Connector Diameter	6.2 mm (Copper)
Suction Connector Diameter	8.2 mm (Copper)
Motor Speed	2900 rpm
LBP Cooling Capacity	611 W
LBP COP	1.63 W/W

Check Before You Order

Verify the compressor model number NLE12.6CNL matches the unit's data plate exactly.
Confirm the system operates on R290 refrigerant.
Ensure the power supply required is 220-240V/50Hz.
Check suction (8.2 mm), discharge (6.2 mm), and process (6.2 mm) line diameters against your existing pipework.

Fitting Notes

Installation requires a current ARCtick licence for refrigerant handling.
Always isolate power and follow lockout/tagout procedures before commencing work.
Ensure the system is properly evacuated and charged to manufacturer specifications after replacement.
Replace the system filter drier when replacing the compressor.

Ordering & Availability

This is a genuine Secop NLE12.6CNL compressor. Sold individually. Current stock levels and estimated lead times are provided at checkout. Order from HVAC Trade Supply.

Commonly Ordered With

Commonly ordered with a new filter drier, a pressure switch, and appropriate R290 refrigerant.
