Which units or series does it fit, and how do I confirm against mine?

The Secop NL11MF compressor fits medical and stationary cooling applications requiring R134a with MBP or HBP conditions. Confirm fitment by matching the existing compressor's model number, refrigerant type, and electrical specifications on your unit's data plate.

Does fitting this part require a licensed tradesperson (ARCtick or electrical)?

Yes, all work involving refrigerant circuits, including compressor replacement, must be performed by an ARCtick licensed technician. Any associated electrical work requires a licensed electrician.

What do I measure or check to be certain before I order?

Before ordering the NL11MF, confirm the operating voltage (220-240V/50Hz), required refrigerant (R134a), and application type (MBP/HBP) from your unit's specifications. Additionally, verify the physical dimensions and connector diameters against your existing compressor.

Secop Compressor R134a 220-240V/50Hz NL11MF

$224.00 - $224.00

$224.00

$224.00 - $224.00

$224.00

🔧 Need the Right HVAC Tool for the Job? Whether you're quoting a bulk order or chasing hard-to-find tools, we’re here to help.

Get a fast, personalised quote—no pressure, no spam!
Fill out the form below and we’ll get back to you ASAP.

📩 Request a Quote

The Secop NL11MF is a fixed-speed compressor designed for R134a refrigerant applications. It operates on 220-240V/50Hz power and is suitable for Medium (MBP) and High Back Pressure (HBP) systems.

Part Identification

Part Number: NL11MF
Manufacturer Part Number (MPN): NL11MF
Brand: Secop
Product Category: Hermetic Compressor
Variant Code Numbers: 105G6156, 105G6151, 105G6154, 105G6159

No supersession data is listed for this part number.

Where This Part Is Used

Stationary cooling solutions
Medical cooling solutions
Medium Back Pressure (MBP) applications
High Back Pressure (HBP) applications

Model coverage can change across production runs — confirm against your unit's data plate before ordering.

Specifications

Power Supply	220-240V/50Hz
Refrigerant Compatibility	R134a
Application Range	MBP, HBP
Motor Type	RSIR, CSIR
Displacement	11.15 cm³
Oil Charge	300 cm³
Oil Type	POE
Height	203 mm
Weight	10.5 kg
Discharge Connector Ø	6.2 mm / 6.5 mm (depending on variant)
Discharge Material	Copper
Process Connector Ø	6.2 mm / 6.5 mm (depending on variant)
Process Material	Copper
Suction Connector Ø	8.2 mm
Suction Material	Copper
Motor Speed	2900 rpm
MBP Cooling Capacity	623 W
HBP Cooling Capacity	1115 W

Check Before You Order

Verify the existing compressor's model number and operating voltage against the NL11MF specifications.
Confirm the refrigerant type required for your system is R134a.
Measure the existing suction, discharge, and process connector diameters to ensure fitment.
Check if your application requires a Medium Back Pressure (MBP) or High Back Pressure (HBP) compressor.
Ensure the physical dimensions, particularly height and mounting, align with the available space in your unit.

Fitting Notes

The refrigeration system must be fully recovered and isolated before compressor replacement.
Always replace the filter drier when installing a new compressor.
Ensure the correct type and volume of POE oil are used during installation.
Installation and commissioning of this refrigeration component must be carried out by an ARCtick licensed technician.
All electrical connections must be performed by a licensed electrician.

Ordering & Availability

The Secop NL11MF compressor is a genuine OEM part. Sold individually. Stock levels and current lead times are displayed at checkout. Order from HVAC Trade Supply.

Commonly Ordered With

Commonly ordered with suitable filter driers, compressor starting relays, and system line taps.
